TOPP Window Automation

Chain actuator

Topp Window Automation Application

Applications
  1. Top-hung windows
  2. Bottom-hung windows
  3. Bottom-hung windows
  4. Skylights, roof windows
  5. Cupolas

C20 : Thrust force 300 N, Max. stroke 360 mm

Electric C20 actuator with double link articulated chain, enclosed in a special casing, with different mounting accessories for top and bottom hung windows.
Operation at 230V 50Hz or, as an alternative, at 24V DC. Maximum applicable load 300N. Fast hooking and unhooking system of the chain to the window. Adjustment of the stroke at 240 or 360mm by an external knob.
CE marked device.

  • Double link chain with very high resistance on top loads
  • High stroke, together with a slim and attractive housing, to allow applications that require minimum size (International patent on the chain path)
  • Stroke end by amperometric absorption in closing to avoid chain adjustments in closing and any possible installation mistake.

C30 : Thrust force 300 N, Max. stroke 380 mm

Electric C30 actuator with double link articulated chain, enclosed in a special casing, with different mounting accessories for top and bottom hung windows. Operation at 230V 50Hz or, as an alternative, at 24V DC. Maximum applicable load 300N. Fast hooking and unhooking system of the chain to the window. Adjustment of the stroke at 200 or 380mm by an external knob. Electronic device with acoustic warning to signal erroneous installation to the user.
Upon request, a preset S version for the synchronous operation of more actuators on the same window is available.
CE marked device.

  • Telescopic chain end providing a rapid adjusting from 0 to 15mm, even with chain completely retracted into the actuator housing, that allows easy application on windows with overlap.
  • Easy fixing system, fit for windows of any type and size.
  • Double link chain with very high resistance on top loads

ACK4 : Thrust force 300 N, Adjustable stroke max. 400mm

Electric actuator Topp model ACK4 with a double link articulated stainless steel chain, enclosed in a special diecast aluminum casing, painted with epoxy powders, with different mounting accessories for top and bottom hung windows. Operation at 230V 50Hz, as an alternative, at 24V DC. Max. traction and thrust force 300N. End of stroke adjustable at 100, 150, 200, 205, 300, 350, 400 mm by an external knob located on both sides of the actuator. Electronic device with acoustic warning to signal erroneous installation (buzzer).

Upon request, a preset S version for the synchronous operation of more actuators on the same window is available.
High protection IP 55 rated. CE marked device.

  • Easy stroke adjustment (7 positions from 100 to 400mm) – International patent
  • Double link articulated stainless steel chain
  • High protection IP 55 rated

Topp Window Automation

Linear stem actuator

TOPP Window AutomationApplications
  1. Top-hung windows
  2. Top-hung windows
  3. Cupolas
  4. Louvered windows
  5. Louvered windows

SL60 : Thrust force 600 N, Max. stroke 750 mm

Linear electric actuator Topp model SL60 with self-aligning tilting mouve- ment, complete with support and fitting accessory for top hung windows.
Operation at 230V 50Hz, or, as an alternative, at 24V DC. Max. traction and thrust force 600N.
Preset for the parallel connection of two or more actuators, with stroke end microswitches. Available strokes: 180 – 230 – 350 – 550 – 750 mm.
CE marked device.

  • Easy and fast installation due to the coupling railways along the shaft in support of the robust stainless steel mounting bracket
  • Rapid coupling system between housing and motor-gear unit
  • High protection IP 55 rated

Topp Window Automation

TOPP Window Automation

C20

Chain actuator

Thrust force 300 N

Max. stroke 360 mm

Chain Actuator C30

C30

Chain actuator

Thrust force 300 N

Max. stroke 380 mm

Chain Actuator ACK4

ACK4

Chain actuator

Thrust force 300 N

Adjustable stroke max. 400mm

Rack Actuator T50

T50

Rack actuator
Thrust force 500 N – Adjustable stroke Max. 1000 mm

Linear electrical actuator, model T50, with self-aligning swivel movement, with stroke, complete with brackets and fitting accessories for top hung windows. Available at 230V 50Hz or at 24V DC. Max. applicable force 500N, max. stroke 1000mm +/- 20mm.
Stroke adjustable about every 50mm by external adjusting selector. Preset for the mechanical connection of 2 or more push points by transmission rod.
S version for simultaneous synchronization and operation of more actuators installed on a single window (without connecting bar) available on demand.
CE marked device.
